3 Operation
3.5.2 Lenze AC Tech EPM
Lenze AC Tech Product Type
EPM Attributes
SCF SCD SCL SCM TCF TML TMD SMD SMV 8400
Baseline
8400
motec
940/941
PositionServo
Master EPM color
Black, blue or gray Blue Blue or gray White
Target EPM color
Gray
1
Blue Gray
1
White
2
Data validity check
Yes
3
Yes
3
Yes
3
Yes
3
Yes
3
Yes
3
Yes
3
No
4
Drive parameters copied
Yes Yes Yes Yes Yes Yes Yes Yes
Vector calibration
information copied
Not applicable No
6
No
6
N/A Yes
7
Yes Yes N/A
Timer information copied
8
Not applicable No No No No Yes No N/A
Fault history copied
No No No No No Yes No Yes
OEM area created
9
Yes Yes Yes Yes Yes No No No
Target EPM is an exact
copy of Master EPM.
No No No No No No No Yes
1. Gray EPM bulk pack(10) part number = EEPM2BA.
2. White EPM bulk pack (10) part number = EEPM2WA.
3. EPM validity checked prior to copying. An EPM that contains invalid data will not be copied.
4. No validity check is performed on EPM data. All EPM data is copied as is.
5. Drive parameters include all parameters listed in drive’s Operating Instructions and Communcations Reference Guide
manuals.
6. If the EPM is setup for vector speed or vector torque mode, then the drive in which the EPM is inserted will have to be
calibrated before it will be allowed to run.
7. Vector calibration information is only transferred for SMV drives with parameter versions 533 or 541.
8. Timer information includes the inverter’s Mains On Time and Run Time. It may include additional information for
specific models.
9. The OEM area contains settings specific to original equipment manufacturers. The data in this area can ONLY be
written to by the memory module copier.
