Technical data
General electrical data
2
EDK82MV371 DE/EN/FR 6.0
79
L
General technical data
EMC7. Compliance with EN 61800−3/A11
Noise emission
Motor mounting Compliance with limit value classes A and B to
EN 55011
Wall mounting
Compliance with limit value class A to EN
55011
(up to 10 m shielded motor cable)
Compliance with limit value class B to EN
55011
(up to 1 m shielded motor cable)
Discharge current to PE
(to EN 50178)
> 3.5 mA
Enclosure8.
IP 55
(NEMA 250 Type 12)
without protection cover over AIF interface
IP 65
(NEMA 250 Type 4)
with protection cover over AIF interface
Protection measures against Short circuit, earth fault (earth−fault protected during operation, limited
earth−fault protection during power up), overvoltage, motor stalling, motor
overtemperature (input for PTC thermistor or thermostat (NC contact), I
2
t
monitoring)
Insulation of control circuits Safe mains disconnection:
Double/reinforced insulation to EN 50178
Operation at public mains
(limitation of harmonic
currents according to EN
61000−3−2)
Total power connected
to the mains
Compliance with the requirements
1)
0.25 kW ... 0.75 kW With mains choke
> 1 kW without additional measures
1)
The additional measures described only ensure that the controllers meet the requirements
of the EN 61000−3−2. The machine/system manufacturer is responsible for the compliance
with the regulations of the machine!
Operation at rated power
Typical motor power P
r
[KW] 0.25 0.37
8200 motec Type E82MV251_2B E82MV371_2B
Mains voltage range V
r
[V]
1/N/PE AC (2/PE AC) 180 V − 0 % ... 264 V + 0 %
(45 Hz − 0 % ... 65 Hz + 0 %)
Data for operation with 1/N/PE AC 230 V 230 V
Rated mains current I
r
[A] 3.4 5.0
Output current 8 kHz
*
I
r8
[A] 1.7 2.4
Max. permissible output
current for 60 s
8 kHz
*
I
max8
[A] 2.5 3.6
*
Inverter chopper frequency
