12 Error messages
12.2 Possible causes and remedies
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.2 Possible causes and remedies
This chapter lists all PROFIBUS error messages in the numerical order of the error numbers. Possible
causes and remedies as well as responses to the error messages are described in detail.
Connection to 8400 standard device lost [0x01bc3100]
Memory: No access [0x01bc5531]
Memory: Read error [0x01bc5532]
Memory: Write error [0x01bc5533]
Restart after watchdog reset [0x01bc6010]
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault : Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• Network cable (plug) is defective.
• Network cable is not connected to the PROFIBUS
terminal X201.
• Voltage supply is interrupted.
Check cables and terminals.
Connect network cable to the PROFIBUS terminal X201.
Response (Lenze setting printed in bold) Setting: not possible
None  System fault : Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Access to memory was not possible. Repeat the download of the application
(including module)
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault : Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Parameter could not be read. Repeat the download of the application
(including module)
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault : Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Parameter could not be written. Repeat the download of the application
(including module)
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault : Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Module defective. If this occurs repeatedly, contact the Lenze service.
