Measure engine
AUX Engine 1
Cylinder no: 01
Cycles: 010
Measure engine
AUX Engine 1
Cylinder no: 01
Boost: 0,50
Cycles: 010
Cycles: 010
Boost: 0,50
Boost: 0,50
Cycles: 010
Boost: 0,50
Boost: 0,50
Measure engine
Start measurement?
No Yes
}
}
Measuring engine ...
AUX Engine 1
Cancel
Measuring engine ...
AUX Engine 1
RPM: 240
Cancel
Measuring engine ...
AUX Engine 1
Calculating ...
}
}
Measurement finished
1.Close valve!
2.Disconnect sensor!
3.Hit key to confirm
11) The number of measuring cycles can be adjusted with the arrow
keys or . Confi rm the value by .
13) Start the measurement with the key
. During the measurement
the ACT display fl ashes blue.
12) In the following display the boost pressure can be adjusted with the
or button. Confi rm with the key .
After the measurement is fi nished the results are calculated.
14) Close the indicator valve completely.
15) Unscrew the pressure sensor. Due to expansion of the sealing cone in
the pressure sensor the hollow key may be required for unscrewing.
CAUTION
After completion of the measuring series, remove the pres-
sure sensor from the indication bore in order to avoid overhe-
ating.
NOTICE
If the pressure sensor does not come loose, open the indi-
cator valve for a short time to achieve a loosening through
the combustion pressure. Close this valve immediately after
removing the pressure sensor from the indicator valve.
16) For security reasons confi rm the correct performance of steps 14
and 15 by the key .
