Levitronix BPS-200.3 User Manual

User Manual for BPS-200
www.levitronix.com
PL-4012-00, Rev07, DCO# 20-144
5
System Name
Article #
Pump Head
Motor
Controller
Note
BPS-200.3 / 4
100-90193 / 94
LPP-200.1
(High Viscosity and
Density)
BSM-1.4
LPC-200.1 / 2
Direct cabling between motor and controller.
BPS-200.1 / 2
100-90191 / 92
BSM-1.3
LPC-200.1 / 2
Adaptor (0.5 - 10m) cables can be ordered according to Table 3.
BPS-200.14 / 15 (ATEX)
100-90556 / 57
BSM-1.6 (ATEX)
LPC-200.1 / 2
Adaptor (0.5 - 10m) cables can be ordered according to Table 3. ATEX Cable Sealing
System can be ordered according to Error! Reference source not found.. ATEX and
IECEx certified.
BPS-200.37 / 24
100-90773 / 03
LPP-200.11
(Improved bubble and
priming behavior)
BSM-1.4
LPC-200.1 / 2
Direct cabling between motor and controller.
BPS-200.40 / 41
100-90776 / 77
BSM-1.3
LPC-200.1 / 2
Adaptor (0.5 - 10m) cables can be ordered according to Table 3.
BPS-200.44 / 45 (ATEX)
100-90780 / 81
BSM-1.6 (ATEX)
LPC-200.1 / 2
Adaptor (0.5 - 10m) cables can be ordered according to Table 3. ATEX Cable Sealing
System can be ordered according to Table 4. ATEX and IECEx certified.
BPS-200.50 / 51 (ATEX)
100-91110 / 11
LPP-200.10 (Antistatic)
BSM-1.6 (ATEX)
LPC-200.1 / 2
Table 1: Standard system configurations
Note 1: All systems are CE, IECEE (following CB scheme) and ETL (NRTL) certified.
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
1b
1c
Pump Head
LPP-200.1
(High Viscosity/Density)
LPP-200.11
LPP-200.10 (Antistatic)
(Improved priming/bubble
behavior)
100-90281
100-90702
100-90684
Impeller / Pump Housing
Sealing Ring
Fittings
LPP-200.1/11: High Purity PFA / PTFE LPP-200.10: PFA / antistatic PTFE
Kalrez

perfluoroelastomer
1
LPP-retek
2
LPP-200.10: 
Max. Flow
Max. Diff.-Pressure
Max. Viscosity / Density
Max. Liquid Temp
21 liters/min / 55 gallons/min
2.6 bar / 37.7 psi
LPP-200.1/x: 50cP / 1.8 g/cm3 LPP-200.11/10: < 20 cP
90
0
C / 194
0
F
Pumphead Selection
LPP-200.1: Usage for higher viscosity and density
LPP-200.11: Usage for aqueious liquids and improved priming/bubble robustness
2a
Motor
BSM-1.4
100-10005
Housing
ETFE (chemical resistant) coated Aluminum, waterproofed (IP67)
Cable / Connectors
1x 5m cables with FEP jacket / 1x D-SUB (direct cable to controller)
2b
Motor
BSM-1.3
100-10004
Cable / Connectors
1x 2m cable with FEP jacket / 1x circular (M23, IP-67)
(needs extension adaptor cable for connection to controller)
2c
Motor (ATEX / IECEx)
BSM-1.6
100-10063
Cable / Connectors
1x 2m cable with FEP jacket / 1x circular (M23, IP-67)
(needs extension adaptor cable for connection to controller)
ATEX / IECEx Marking
II 3G Ex nA IIC T5 Gc II 3D Ex tc IIIC T100°C Dc
3a
Standalone
Controller
(User Panel)
LPC-200.1
100-30008
(Controller with
PLC connector
incl. in 100-
90335)
Electrical Power / Voltage
200 W / 24 - 48V DC
Interfaces for
Standalone Controller
Panel to set speed (automatic storage on internal EEPROM)
PLC with
 4 - 20 mA
 0 - 24 V (optocoupler)
 0 - 24 V (relais)
Standard Firmware
C2.25
3b
Extended
Controller
(PLC and USB)
LPC-200.2
100-30009
(Controller with
PLC connector
incl. in
100-90336)
Interfaces for
Extended Controller
PLC with
- up to 4 digital inputs 0 - 24V (optocoupler)
- up to 4 digital outputs 0 - 24 V (relais)
- up to 2 analog inputs 4 - 20mA
- up to 2 analog inputs 0  10 V
- up to 2 analog outputs 0  5 V
USB interface (for service and system monitoring)
Standard Firmware
C2.48
Table 2: Specification of standard components
Note 1: Kalrez

is a registered trademark of DuPont Dow Elastomers Note 2: Pump head
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
4
Extension Adaptor
Cable for Power
MCA-1.4-05 (0.5m)
MCA-1.4-30 (3m)
MCA-1.4-50 (5m)
MCA-1.4-70 (7m)
MCA-1.4-100 (10m)
190-10228
190-10170
190-10187
190-10229
190-10230
Jacket Material
Connectors
PVC-jacket
Circular Hummel to D-SUB connector
Table 3: Specification of adaptor/extension cables
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
5
Air Cooling Module
ACM-1.1
190-10003
Material / Connection Port
Air Pressure / Consumption

~ 0.5bar (7.2 psi)
6
Mounting Base Plate
MBP-1.1
190-10004
Material
PVDF
7
(a,b
,c,d
,e)
Impeller Exchange
Kits
IEK-200.1 (for LPP-200.1)
IEK-200.2 (for LPP-200.11)
IEK-200.8 (for LPP-200.10)
100-90517
100-90524
100-91109
Impeller (a) / Sealing O-Ring (b)
Pump Casing Screws (c)
Pump Motor Screws (d)
Exchange Tool IET-1.1 (e)
PFA / O-Ring, Kalrez, 50.52 x 1.78
IEK-200.1/2: 6 pcs M4 x 15 mm, PVDF
IEK-200.8: 6 pcs M4 x 16 mm, PTFE coated stainless steel
IEK-200.1/2: 4 pcs M3 x 16 mm, PVDF
IEK-200.8: 4 pcs M3 x 14 mm, stainless steel (SS)
POM-C
8
Ex Cable
Sealing System
ACS-A.1
100-90292
Sleeve (a) / Gasket (b)
Frame (c)
Cable Module (d)
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Roxylon (EPDM rubber)
Note:
Lubricant (e) and measurement plates
(f) are included.
9a
AC/DC Power Supply
TSP 360-124
(Standard Traco Supply)
100-40016
Voltage / Power Output /
Voltage Input
Dimensions
24 VDC / 360 W
85  132 / 187  264 VAC, autoselect
125 x 125 x 80 mm
Certification
UL, CSA, CB, Semi F47
9b
AC/DC Power Supply
TSP 360-148
100-40017
Voltage / Power Output
48 VDC / 360 W (other specifications same as 9a)
10
Screw Set
Screw Set
SS+PTFE
100-90447
Number/Dimensions
Material
4 pcs M3x14 and 6 pcs M4x16
Stainless Steel+ PTFE coating
Needed to increase maximum static
pressure of pump head.
Table 4: Specification of accessories
