The driver can be fixed with four screws on the motor feet (see Figure 13, Figure 14 and Figure 15).
Mounting can be done in either in horizontal or vertical position.
When mounting the pump head fittings into a circuit it has to be taken care that no mechanical stress is
acting on the fittings, which can result in distorting creeping effects. The outlet orientation of the pump head
can be changed in steps of 45° by assembling the pump head accordingly (see Figure 32).
Figure 32: Vertical and 45° orientation of pump head with rotation of pump head
For higher chemical resistance of the connectors of the EasyConnect model protective covers are available
(see Table 3 for order information) as illustrated in Figure 33.
