4.2.5 Display Messages
Priority
Event
Display Message
Digit 1 – 4
Status Description
1
2
3
4
1
Download
–
d
l
-
- Firmware download running
- Blinking
2
Volume counter reset
C
L
E
A
- Volume counter is reset
3
Zero adjustment
0
A
d
J
- Zero adjustment is running (approximately 2 sec.)
- Blinking
4
Zero adjustment error
0
–
E
r
Zero adjustment error
5
Volume counter pulse set error
P
–
E
r
Volume counter pulse length is too big to show full scale flow on digital
output
6
Measurement error
b
–
E
r
- Sensor signal error -> empty sensor, bubble, etc.
- Blinking
7
Warning upper limit
H
- Displays upper limit warning (with flow rate display by turns)
- Blinking with flow rate
Warning lower limit
L
- Displays lower limit warning (with flow rate display by turns)
- Blinking with flow rate
Exceeds vol. counter value H
H
- Volume counter value exceeded preset H
- Blinking with flow rate
Exceeds vol. counter value HH
H
- Volume counter value exceeded preset HH
- Blinking with flow rate
8
Flow rate display
X.
X
X
X
Flow rate range: 0.000 ~ 9.999 L/min
X
X.
X
X
Flow rate range:10.00 ~ 99.99 L/min
Table 14: Display messages of LFC-1C / LFC-1C-F4 converter
(Same messages for LFC-6C and LFC-6CIO)
