Levitronix LEVIFLOW LFC-1C User Manual

User Manual for LEVIFLOW
®
LFS Flowmeters
www.levitronix.com
PL-4502-00, Rev11, DCO# 18-107
7
Figure 6: Flowmeter configuration with LFC-6CIO converter (6 channel with I/O interfaces)
LEVIFLOW
®
Converter LFC-6CIO
(6-Channel with I/O Signals)
4-Digit Display
Zero Adjustment
Address Setting for RS485
Piezo Transducers In-/Output
Signal/Power Bus Connector
Power Supply: 24 VDC
RS485 (MODBUS)
- Configuration with PC Software
- Data Reading
Digital
Signal Processor
DSP
Flowsensor LFS
Flowsensor LFS
Flowsensor LFS
Flowsensor LFS
Flowsensor LFS
Flowsensor LFS
Analog Output
Connector
Digital I/O
Connector
Analog Outputs:
6 Channels
Digital Outputs:
6 Channels
Digital Inputs:
6 Channels
EMI
Ferrite
4
8
1
5
6
4b
4a
