// 0:Level Mode

// 1:Pulse Mode

#deﬁ ne GPIO3X_Output_Data 0x41 // GPIO3x Output Data Register

#deﬁ ne GPIO3X_PULSE_WIDTH_CONTROL 0x44 // GPIO3x Pulse Width Control Register

#deﬁ ne GP3_PSWIDTH_500US 0x00 // When select Pulse mode: 500 us.

#deﬁ ne GP3_PSWIDTH_1MS 0x01 // When select Pulse mode: 1 ms.

#deﬁ ne GP3_PSWIDTH_20MS 0x02 // When select Pulse mode: 20 ms.

#deﬁ ne GP3_PSWIDTH_100MS 0x03 // When select Pulse mode: 100 ms.

//--------------------------------------------------------------------------------------------------------

#deﬁ ne WDT_TIMER_RANGE 0x37 // 0-255 (secord or minute program by WDT_UNIT)

#deﬁ ne WDT_CONFIGURATION 0x36 // Conﬁ gure WDT Function

#deﬁ ne WDT_TIMEOUT_FLAG 0x40 // When watchdog timeout.this bit will be set to 1.

#deﬁ ne WDT_ENABLE 0x20 // Enable watchdog timer

#deﬁ ne WDT_PULSE 0x10 // Conﬁ gure WDT output mode

// 0:Level Mode

// 1:Pulse Mode

#deﬁ ne WDT_UNIT 0x08 // Watchdog unit select.

// 0:Select second.

// 1:Select minute.

#deﬁ ne WDT_LEVEL 0x04 // When select level output mode:

// 0:Level low

// 1:Level high

#deﬁ ne WDT_PSWIDTH_1MS 0x00 // When select Pulse mode: 1 ms.

#deﬁ ne WDT_PSWIDTH_20MS 0x01 // When select Pulse mode: 20 ms.

#deﬁ ne WDT_PSWIDTH_100MS 0x02 // When select Pulse mode: 100 ms.

#deﬁ ne WDT_PSWIDTH_4000MS 0x03 // When select Pulse mode: 4 s.
