Lex Computech CI770C - Serial Port 1 Configuration & Serial Port 2 Configuration

63
4-7-7-1 ►Serial Port 1 Confi guration & Serial Port 2 Confi guration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
Serial Port 1~2 Confi guration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [AUTO]
COM1 422/485 control fl ow [Disabled]
COM2 422/485 control fl ow
[Disabled]
Enable or Disable Serial
Port (COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Use this item to enable or disable serial port (COM).
The optional settings are: Enabled, Disabled.
Use this item to enable or disable serial port (COM) Autofl ow
The optional settings are: Enabled, Disabled.
Use this item to select an optimal setting for super IO device.
The optional settings are:
AUTO
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4,5,6,7,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,10,11,12;
Serial Port
COM1 422/485 control fl ow
Change Settings
4-7-8 F17869 H/W Monitor
Press [Enter] to view PC health status.
This section shows the status of your CPU, Fan, and overall system.
This is only available when there is Hardware Monitor function onboard.
F17869 H/W Monitor
