Lex Computech CI770C - Sata Configuration; Sata Mode Selection-Ahci Mode

59
4-7-4 SATA Confi guration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
SATA Controller(s) [Enabled]
SATA Mode Selection [IDE]
Enable or disable SATA
Device.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Use this item to Enable or Disable SATA Device.
Determine how SATA controller(s) operate.
The optional settings are: IDE Mode, AHCI Mode.
SATA Controller(s)
SATA Mode Selection
4-7-4-1 SATA Mode Selection - AHCI Mode
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
SATA Controller(s) [Enabled]
SATA Mode Selection [AHCI]
SATA Controller Speed [Gen3]
►Software Feature Mask Confi guration
Enable or disable SATA
Device.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Indicates the maximum speed the SATA controller can support.
The optional settings: Gen1, Gen2, Gen3.
SATA Controller Speed
Please refer section 4-7-4-1-1
Software Feature Mask Confi guration
