4-7-9 F81216 Second Super IO Confi guration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
F81216 Second Super IO Confi guration
F81216 Second Super IO Chip F81216 SecondIO
►Serial Port 3 Confi guration
►Serial Port 4 Confi guration
►Serial Port 5 Confi guration
►Serial Port 6 Confi guration
Set Parameters of Serial
Port 3(COMC)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Please refer section 4-7-9-1
Please refer section 4-7-9-1
Please refer section 4-7-9-1
Please refer section 4-7-9-1
Serial Port 3 Confi guration
Serial Port 4 Confi guration
Serial Port 5 Confi guration
Serial Port 6 Confi guration
4-7-9-1 Serial Port 3~6 Confi guration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
Serial Port 3~6 Confi guration
Serial Port [Enabled]
Device Settings IO=260h; IRQ=11;
Change Settings [AUTO]
COM3 422/485 control fl ow [Disabled]
Enable or Disable Serial
Port (COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
