SIM1,SIM2: SIM card socket pin defi ne is follow ISO 7816-2 smart card
SODIM1/2: SO-DIM DDR3 1.5V DRAM Socket
PIN NO. Description PIN NO. Description
1 Vcc 1 GND
2 RST 2 Vpp
3 CLK 3 DATA
4 RUF 4 RUF
Note: 1. MPCE1 Pin 8, 10,12,14,16 for SIM1 card reader use.
2. MPCE2 Pin 8, 10,12,14,16 for SIM2 card reader use.
3-19 SIM Socket
3-20 SODIMM socket
SIM1
SIM2
SODIMM1
SODIMM2
