18
2-6 Install Memory
Valid Memory Confi gurations
Please refer to page 9 for installation of memory module.
DIMM1 / 2
NOTE!
System Accept or Not
Total Memory
DS Accept
Max.
16GB
This motherboard provides one 204-pin Small Outline Dual In-line Memory Module (SODIMM)
socket for memory expansion available maximum to of 2GB/4GB/8GB DDR3 SDRAM.
DDR3 clock supports: DDR3 1333/1600MT/S
The detected memory size is less than actual installed memory size since
some memory has been allocated for system use.
That’s how PC works with system memory.
