Lex Computech CI770C - Mini Pcie 1;2

68
Please refer section 4-8-1-1-2
PCI Express x1
Please refer section 4-8-1-1-2
PCI Express x1
4-8-1-1-1 ►Mini PCIe 1/2
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
PCI Express Root Port 3/4 [Enabled]
PCIe Speed [Gen1]
Control the PCI
Express Root Port.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Control the PCI Express Root Port.
The optional settings are: Enabled, Disabled.
Select PCI Express port speed.
The optional settings are: Auto, Gen1, Gen2.
PCI Express Root Port 3/4
PCIe Speed
4-8-1-1-2 ►PCI Express x 1
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
PCI Express Root Port 7/8 [Enabled]
PCIe Speed [Gen1]
Control the PCI
Express Root Port.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Control the PCI Express Root Port.
The optional settings are: Enabled, Disabled.
PCI Express Root Port 7/8
