4-8-1 ►PCH-IO Confi guration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
Intel PCH SKU Name QM77
Intel PCH Rev ID 04/C1
►PCI Express Confi guration
►USB Confi guration
►PCH Azalia Confi guration
Wake on LAN [Disabled]
PCI Express
Confi guration settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Please refer section 4-8-1-1
Please refer section 4-8-1-2
Please refer section 4-8-1-3
Use this item to enable or disable integrated LAN to wake the system.
PCI Express Confi guration
USB Confi guration
PCH Azalia Confi guration
Wake on LAN
4-8-1-1 ►PCI Express Confi guration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced
PCI Express Confi guration
►Mini PCIe 1
►Mini PCIe 2
►PCI Express x1
►PCI Express x1
PCI Express
Confi guration settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Please refer section 4-8-1-1-1
Mini PCIe 1
Please refer section 4-8-1-1-1
Mini PCIe 2
