Chapter-3
3-1 List of Connectors
Connection
This chapter provides all necessary information of the peripheral's connections,
switches and indicators. Always power off the board before you install the peripherals.
CA12: Mic-in (down side) / Line out (up side) phone jack.
CA3: Line-out/Line-in/Mic-in 2x5 pin (2.0mm) wafer.
CAL1: Amplifi er Line-out Left channel 2pin (2.0mm) wafer.
CAR1: Amplifi er Line-out Right channel 2pin (2.0mm) wafer.
SPDIF1: SPDIF audio output connector. (Option)
CC12: COM1 (up side)/COM2 (down side) dual DB9p connector.
CC11: COM1 2x5pin (2.0mm) wafer (The location share with CC12).
CC13: COM1 1x5pin (1.25mm) wafer.
CC2: COM2 DB9p connector (The location share with CC12).
CC21: COM2 2x5pin (2.0mm) wafer (The location share with CC12).
CC34: COM3 (up side)/COM4 (down side) dual DB9p connector.
CC31: COM3 2x5pin (2.0mm) wafer (The location share with CC34).
CC4: COM4 DB9p connector (The location share with CC34).
CC41: COM4 2x5pin (2.0mm) wafer (The location share with CC34).
CC5: COM5 2x5pin (2.0mm) wafer.
CC6: COM6 2x5pin (2.0mm) wafer.
CC7: COM7 2x5pin (2.0mm) wafer.
CC8: COM8 2x5pin (2.0mm) wafer.
CC9: COM9 2x5pin (2.0mm) wafer.
CC10: COM10 2x5pin (2.0mm) wafer.
CDG1: DVI-D (down side) / VGA (Up side) DB15p connector.
CG11: VGA port 2x5 pin (2.0mm) wafer.
HDMI1: HDMI type A connector.
LVDS1: LVDS 2x15 pin (1.25mm) connector.
CPP1: Panel inverter power connector 1x5 pin (2.0mm) wafer.
CT1: Touch screen device 2x5 pin (2.0mm) Wafer.
CIO1: DI port 0 ~ 3, DO port 0 ~ 3 2x5 pin (2.0mm) wafer.
CIO2: DI port 4 ~ 7, DO port 4 ~ 7 2x5 pin (2.0mm) wafer.
CIO3: DI port 8 ~11, DO port 8 ~ 11 2x5 pin (2.0mm) wafer (option).
CIO4: DI port 12 ~15, DO port 12 ~ 15 2x5 pin (2.0mm) wafer (option).
CKM1: KB/MS port 1x6 pin (1.25mm) wafer connector.
