The on-line description of the highlighted setup function is displayed at the top right corner
the screen.
Main To change system basic confi guration
Advanced To change system advanced confi guration
Chipset To change chipset confi guration
Boot To change boot settings
Security Password settings
Save & Exit Save setting, loading and exit options.
User can press the right or left arrow key on the keyboard to switch from menu bar.
The selected one is highlighted.
Press F1 to pop up a small help window that describes the appropriate keys to use and
the possible selections for the highlighted item. To exit the Help Window, press <Esc>.
4-4 Getting Help
4-5 Menu Bars
4-6 Main
Main Menu
There are six menu bars on top of BIOS screen:
Status Page Setup Menu/Option Page Setup Menu
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main menu screen includes some basic system information. Highlight the item and then use
the <+> or <-> and numerical keyboard keys to select the value you want in each item.
Main Advanced
BIOS Vendor CI770C/A
Processor Information
Name IvyBridge
Brand String Intel(R) Core(TM) i7
Frequency 2300 MHz
Total Memory 2048 MB (DDR3)
Memory Frequency 1333 MHz
System Date [Tue 01/15/2013]
System Time [19:28:51]
Set the date. Use Tab
to Switch between
date elements.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Chipset
Boot
Security
Save & Exit
Set the Time. Please use [Tab] to switch between data elements.
Set the Date. Please use [Tab] to switch between data elements.
System Time
System Date
To Next Page
