87
5.
At the "Readme File Information"screen,
Click "Next".
6.
At the "Setup Progress" screen,
Click "Next".
NOTE: The path of the
fi
le
For Windows XP
32/64 bit and Windows 7 32/64-bit
X:\driver\INTEL\ME TOOL\MEI-Only Installer\MEISetup.exe
92
94
