Lexmark C510 Service Manual

2-54 Service Manual
5021-0XX
915—Erase lamp service check
Step Questions / actions Yes No
1 Turn printer off and remove
toner cartridges and
photodeveloper cartridge.
Check erase lamp cable for
proper connection. Is erase
lamp cable properly
connected?
Go to step 2. Properly connect
erase lamp.
Retest printer. If
error clears,
problem solved,
otherwise go to
step 2.
2 Check erase lamp for any
visible damage. Is erase
lamp damaged?
Replace erase
lamp. See
“Erase lamp
removal” on
page 4-27.
Retest printer. If
error clears,
problem solved,
otherwise
remove toner
cartridges and
photodeveloper
cartridge and go
to step 3.
Go to step 3.
3 Set multimeter to check
diodes. Looking at erase
lamp through front cover,
touch meter positive lead to
left LED connection and
meter negative lead to right
LED connection. LED
should illuminate. Check all
LEDs on erase lamp board.
Do any LEDs fail to
illuminate?
Replace erase
lamp. See
“Erase lamp
removal” on
page 4-27.
Retest printer. If
error clears,
problem solved,
otherwise go to
step 4.
Go to step 4.
4 Remove I/O board shield.
See “I/O board removal”
on page 4-70 for steps to
remove I/O board shield. Is
cable properly connected
to I/O board connector
DCN15?
Go to step 5. Properly connect
cable. Retest
printer. If error
clears, problem
solved,
otherwise go to
step 5.

Lexmark C510 Specifications

General

Certification	FCC Class B, UL 60950 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, Blue Angel, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, C-tick mark Class B, CCC Class B
Product color	White
Built-in display	-
Color	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	13 s
Time to first page (color, normal)	19 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Print speed (color, normal quality, A4/US Letter)	8 ppm
Maximum internal memory	320 MB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Maximum input capacity	780 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Serial (RS-232)
Maximum duty cycle	- pages per month
Page description languages	PCL 6, PDF 1.3, PostScript 3
Package depth	645 mm
Package width	680 mm
Package height	670 mm
Package weight	40600 g
Operating altitude	0 - 2500 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Power consumption (printing)	- W
Ethernet LAN	No

Weight and Dimensions

Depth	420 mm
Width	495 mm
Height	385 mm
