1-16 Service Manual
5021-0XX
Environment
Environment Specifications
Operating
Air temperature - product operating 10 to 32.5°C (50 to 90.5°F)
Air temperature - product power off 5 to 35°C (41 to 95°F)
Air relative humidity 15 to 80%
Altitude 0 - 2,500 m (0 - 8,200 ft.)
Ship / Storage
Temperature-printer and supplies 0 to 35°C (32 to 95°F)
1
Relative humidity 10 to 90% RH
Atmospheric pressure 613 to 16057 hPa (460 to 800 mm Hg)
1
Severe High 35 to 40°C (95 to 104°F), Severe Low -10 to 0°C (14 to 32°F). The period
under severe shall not be deemed to be continuous, but rather a total of such
intermittent periods (48 hours at most for any one period).
