Lexmark C510 - Page 327

Locations and connectors 5-23
5021-0XX
18 MMENC 14
17 MMGAIN 15
16 GARESET-N 16
15 RECLON-P 17
14 FBCLON-P 18
13 FBSLON-P 19
12 TRSLON-P 20
11 HTFANON-P/* OZFANON-P 21
10 FUCLON-P 22
9 PKCLU1ON-P 23
8SGND 24
7 DMCLK 25
6DMRDY-N 26
5DMON-N 27
4DMGAIN 28
3TALWDDA 29
2 SEPASLON-P 30
1SGND 31
I2CN
Pin No.
Signal name
DCN3
Pin No.
