12 Duplex unit
Note: The finisher shown above is the booklet finisher. The standard finisher is not shown.
Understanding the control panel
Control panel item Description
1 Display Shows messages and pictures that communicate the status of the printer
2 Indicator light Indicates the printer status:
• Off—The power is off.
• Blinking green—The printer is warming up, processing data, or printing.
• Solid green—The printer is on, but idle.
• Solid red—Operator intervention is needed.
3 Keypad Enter numbers or symbols on the display.
4 Navigation buttons
Press or to scroll through menu lists.
Press
or to scroll through values or text that roll to another screen.
5 Select
Press to initiate action on a menu item.
6 Stop
Stops all printer activity
A list of options is offered once Stopped appears on the display.
7 Menu
Opens the menu index
Note: The menus are available only when the printer is in the Ready state.
Learning about the printer 13
