Lexmark C935 Series - Page 143

6 Remove the tape from the top of the photoconductor.
7 Press the button forward to insert the photoconductor while removing the casing.
8 Lift the bar up, and then press latch E5 down so that it holds the bar in position.
Maintaining the printer 143
