Lexmark CS510de - Page 134

3 Slide the release latch on the right side of the printer, and then open the top door.
1
2
4 Remove the right side cover.
1
2
5 Press the green levers on each side of the waste toner bottle, and then remove the waste toner bottle.
1
2
Maintaining the printer 134
