Repeating defects appear on prints
Action Yes No
Step 1
Measure the distance between the defects.
Check for a distance between the defects that equals:
• 97 mm (3.82 in.)
• 47 mm (1.85 in.)
• 38 mm (1.5 in.)
Is the distance between defects equal to one of the listed measurements?
Go to step 2.
1 Check if the distance
between the defects
equal to 80 mm (3.15
in.)
2 Take note of the
distance, and then
contact
customer
support at
http://support.lex
mark.com or your
service
representative.
Step 2
Replace the imaging unit, and then resend the print job.
Do the repeating defects still appear?
Contact
customer
support at
http://support.lexmark
.com or your service
representative.
The problem is solved.
Shadow images appear on prints
ABCD
ABCD
ABCD
ABCD
Leading edge
Trailing edge
