Lexmark MS810 Series

4 Use the following illustration to locate the appropriate connector:
Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity.
Touch a metal surface on the printer first before touching any controller board electronic component or
connector.
1
3
2
1 Lexmark Internal Solutions Port or printer hard disk connector
2 Option card connector
3 Memory card connector
Additional printer setup 13
