Repair Information 4-39
4062-XXX
Go Back
Previous
Next
5. Remove the screw (B) securing the MPF pick solenoid assembly to the machine.
6. Remove the MPF pick solenoid assembly.
7. Disconnect the connection (C) from the MPF pick solenoid assembly.
B
C
C
