Lexmark T656dne - Print Cartridge Clamp Assembly Removal

Repair Information 4-57
4062-XXX
Go Back
Previous
Next
Print cartridge clamp assembly removal
Note: This procedure can be applied to the left or right printer cartridge hold down assembly.
1. Remove the laser cover. Go to “Laser cover removal” on page 4-26.
2. Remove the screw (A) securing the print cartridge clamp assembly to the machine.
3. Remove the print cartridge clamp assembly.
AB
A
