Repair Information 4-97
4062-XXX
Go Back
Previous
Next
4. Remove the screw (A) securing the appropriate 5-bin mailbox deflector gate solenoid.
5. Remove and unroute the cable to the deflector gate solenoid.
6. Disconnect the proper deflector gate solenoid harness from the controller card.
Note: To ease the cable unrouting, cut the appropriate cable.
A
