Lexmark T656dne - Page 515

Repair Information 4-195
4062-XXX
Go Back
Previous
Next
3. Remove the screw (A) securing the sensor to the rear frame.
4. Release the hooks (B) securing the sensor to the rear frame.
5. Remove the sensor (HCIT tray raised HP).
B
A
