243.66 Pick motor
underspeed failure
Source = Media tray 3
The pick motor does not rotate
at the specified speed.
1. Remove all media present
in media path.
2. Ensure media tray is not
overfilled.
3. Check all connections on
the pick arm assembly.
4. Check all connections on
the system card assembly.
5. Replace the pick arm
assembly if problem
remains. Go to “Pick arm
assembly removal” on
page 4-54.
6. Replace system card
assembly if problem
remains. Go to “System
card assembly removal”
on page 4-75.
243.67 Pick motor overspeed
failure
Source = Media tray 3
The pick motor does not rotate
at the specified speed.
1. Remove all media present
in media path.
2. Ensure media tray is not
overfilled.
3. Check all connections on
the pick arm assembly.
4. Check all connections on
the system card assembly.
5. Replace the pick arm
assembly if problem
remains. Go to “Pick arm
assembly removal” on
page 4-54.
6. Replace system card
assembly if problem
remains. Go to “System
card assembly removal”
on page 4-75.
243.68 Pick motor stop error
Source = Media tray 3
Pick motor stop error detected
by options tray x
1. Remove all media present
in media path.
2. Ensure media tray is not
overfilled.
3. Check all connections on
the pick arm assembly.
4. Check all connections on
the system card assembly.
5. Replace the pick arm
assembly if problem
remains. Go to “Pick arm
assembly removal” on
page 4-54.
6. Replace system card
assembly if problem
remains. Go to “System
card assembly removal”
on page 4-75.
Error
code or
message
Error contents Description/Action Possible repair actions
