2 Lift the front of the scanner unit to open the system board.

3 Use the following illustration to locate the appropriate connector.

Warning—Potential Damage: System board electronic components are easily damaged by static electricity.

Touch something metal on the printer before touching any system board electronic components or connectors.

1 Flash memory or firmware card connectors

2 Fax card connector

3 Lexmark Internal Solutions Port or printer hard disk connector

4 Memory card connector

Additional printer setup 30
