Lexus LS460 - Liquid Crystal Display; System Check Display; Tire Inflation Pressure; When Disconnecting and Reconnecting Battery Terminals

114
2. Instrument cluster
LS460_EE (OM50D49E)
Press and hold the “DISP”
button after selecting the
“EXIT” by pressing the
“DISP” button.
The display goes back to step .
 System check display
After turning the engine switch to IGNITION ON mode, “SYSTEM
CHECK” is displayed while system operation is checked.
 Tire inflation pressure
 It may take a few minutes to display the tire inflation pressure after the
engine switch is turned to IGNITION ON mode. It may also take a few
minutes to display the tire inflation pressure after inflation pressure has
been adjusted.
 “---” may be displayed if the tire position information cannot be determined
due to unfavorable radio wave conditions.
 Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.
 When disconnecting and reconnecting battery terminals
The following information data will be reset:
 Driving range
 Average fuel consumption
 Average fuel consumption after refueling
 Distance after refueling
 Elapsed time
 Average vehicle speed
 Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.
 Customization
Setting of available languages can be changed. (Customizable features P.
906)
5
1
