MAKINGCONNECTIONS
OU
T
V
IDE
O
OUT
V
IDE
O
AU
DI
O
OU
T
AV(COMPOSITE,CVBS)
connection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheMonitorset.Connect
theexternaldeviceandtheMonitorsetwith
theCompositecableasshowninthefollowing
illustration.
Componentconnection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheMonitorset.Connect
theexternaldeviceandtheMonitorsetwiththe
RGB-Componentcableasshowninthefollowing
illustration.
Backoftheproduct.
(notincluded)
(notincluded)
(notincluded)
(notincluded)
Backoftheproduct.
