LG BD430 - Connecting to Computer (Digital and Analog RGB)

19
Installation
Connect to computer (Digital and analog RGB)
Cables used for connection ( *Cables are not supplied with the projector.)
RGB cable (1) Serial cable*
HDMI cable*
Unplug the power cords of both the projector and external
equipment from the AC outlet before connecting the cables.
HDMI
RGB OUT
VIDEO/Y
Pr/Cr
R
L
AUDIO IN
AUDIO OUT
Pb/Cb
S-VIDEO
RGB IN 2
RGB IN 1
RS-232C
MONO
RGB intput
RGB cable RGB cable
HDMI output
RGB output
Serial port
Serial cable HDMI cable
HDMI
RGB output RGB 1 input
Control port
