LG BD430 - Dimensions; PIN Code Memorandum

64
Dimensions
Unit: mm
90.9
101.2
327.4
75.5
167.5
15
92
241
4-M4x10
41.5
68.5
107
Screw hole used when
installed on the ceiling
Screw:M6
Depth:10.0
Appendix
PIN code memorandum
Write down the PIN code in the blank below and keep it, please contact the repair center.
PIN code lock
Logo PIN code lock
Factory default PIN code 111*
Factory default PIN code 111*
*If this 3-digit number is changed,
the factory default number will be ineffective.
