Appendix
RS232 Control Method
NOTE: Connect the PC & projector with serial port cable (female-to-female pins) for projector computer
control.
1. Connection
1.1 Port Setting
1.1 Wiring
RS232 cross cable is used.
Item Value
Method Asynchronous communication
Bits per seconds 19200
Data bits 8
Parity none
Stop bits 1
Flow control none
PC Projector
COM Control Port
（D-Sub 9 Pin） （D-Sub 9 Pin）
