60
Appendix
Compatible Signal
Basically this projector can accept the signal with the V-,H-Frequency mentioned below:
√ Note:
The specication is subject to change without any prior notice.
No.
Specication
Proposed
Resolution H-freq(KHz) V-freq(Hz)
Pixel
clock(MHz)
HDMI-DTV
1 720*576 31.250 50 27 576P
2 720*480 31.47 59.94 27 480P
3 1280*720 37.50 50 74.25 720P
4 1280*720 45.00 60.00 74.25 720P
5 1280*720 44.96 59.94 74.175 720P
6 1920*1080 28.125 50 74.25 1080I
7 1920*1080 33.75 60.00 74.25
1080I
8 1920*1080 33.72 59.94 74.176
1080I
HDMI-PC/RGB-PC
1 640*350 31.47 70.09 25.18
PC98
2 720*400 31.47 70.09 28.32 PC98
3 640*400 37.86 85.08 31.5 VGA
4 640*480 31.469 59.94 25.17 VGA
5 640*480 37.861 72.8 31.5 VGA
6 640*480 37.5 75 31.5 VGA
7 640*480 43.27 85.01 36 VGA
8 800*600 35.156 56.25 36 SVGA
9 800*600 37.879 60.32 40 SVGA
10 800*600 48.077 72.18 50 SVGA
11 800*600 46.875 75 49.5 SVGA
12 800*600 53.67 85.06 56.25 SVGA
13 1024*768 48.363 60 65 XGA
14 1024*768 56.476 70.07 75 XGA
15 1024*768 60.02 75.03 78.75 XGA
16 1024*768 68.68 85 94.5 XGA
17 1152*864 67.5 75 108 XGA+
18 1280*1024 63.981 60.02 108 SXGA
19 1280*1024 79.98 75.02 135 SXGA
20 1280*768 47.776 59.87 79.5 WXGA
21 1280*768 60.29 74.89 102.25 WXGA
22 1280*768 68.63 84.84 117.5 WXGA
23 1360*768 47.71 60.02 85.5 WXGA
24 1366*768 47.13 59.66 72.01 WXGA
25 1280*800 49.7 59.81 83.5 WXGA
26 1280*800 62.79 74.93 106.5 WXGA
27 1280*800 71.55 84.88 122.5 WXGA
28 1280*960 60 60 108 SXGA-
29 1400*1050 65.32 59.98 121.75 SXGA+
30* 1600*1200 75 60 162 UXGA
31* 1680*1050 65.29 59.95 146.25 WSXGA+
No.
Specication
Proposed
Resolution H-freq(KHz) V-freq(Hz)
Pixel
clock(MHz)
Component Video input (Y,Pb,Pr)
1 720*576 15.625 50 13.5 SDTV 576I
2 720*480 15.735 59.94 13.5 SDTV 480I
3 720*576 31.250 50 27
EDTV 576P
4 720*480 31.47 59.94 27
EDTV 480P
5 1280*720 37.50 50 74.25
HDTV 720P/50Hz
6 1280*720 45.00 60.00 74.25
HDTV 720P/60Hz
7 1920*1080 28.125 50 74.25
HDTV 1080I/50Hz
8 1920*1080 33.75 60.00 74.25
HDTV 1080I/60Hz
* RGB signal only.
