Setting the Video Output Resolution

The first time you turn ON the STB/display panel, a Please Select Video Output Resolution menu

will be displayed, and you will need to select the appropriate option—720p, 1080p, or 1366 x 768—

for the STB’s video output format. You cannot proceed with STB configuration until you make a

selection.

Note: After it is turned ON, the STB begins an initialization process, and it may take several minutes

for the Video Output Resolution menu to be displayed.

Refer to documentation for the applicable display panel(s) to determine the appropriate setting.

The selected resolution should be compatible with the display panel’s native video resolution.

PLEASE SELECT VIDEO OUTPUT RESOLUTION

720p

1080p

1366 x 768

1. Use the Up/Down arrows on the Installer Remote to select the appropriate video output

resolution option, and then press OK.

The STB’s default video output resolution is 720p. If you select this option, the Please Select

Video Output Resolution menu will close and the EZ-Manager Wizard Welcome screen will be

displayed (see pages 16 to 25 for information on the EZ-Manager Wizard). Proceed with

Commercial Mode setup as required.

If you select one of the other two resolution options (1366 x 768 is selected/highlighted as the

recommended resolution), a Changing Video Output Resolution message will be displayed, and

the STB will reboot within a few seconds to change the resolution per your selection. Continue

with step 2.

2. When the STB reboot is complete (it may take a few minutes), you will be prompted to conrm

the new video output resolution. Use the arrow keys on the Installer Remote to select YES in the

conrmation screen, and then press OK on the Installer Remote.

Note: If there is no user interaction within 10 seconds, or if you select “NO” in the conrmation

screen, the STB will reboot and revert to the default resolution. After this reboot is complete, the

Please Select Video Output Resolution menu will be redisplayed.

Once you select and conrm the video output resolution, the EZ-Manager Wizard will be displayed.

Proceed with Commercial Mode setup as required.

Note: If required at a later time, you can also change the video output resolution in the STB

Installer Menu (item 105 VID OUT FORMAT) or via USB memory device / TLX le. In either case,

the STB will need to reboot (see item 105 description on page 38 for additional information).
