18
GENERAL INFORMATION
ENGLISH
Product Heating Capacity :
16 kW
U3 Chassis
(unit : mm)
4-holes for anchor bolts
390
360
330
Supporter
1 380
165 165
490
620
950
390
1 356
Outdoor unit : External
No Name
1 Liquid-side Service Valve
2 Gas-side Service Valve
3 Air discharge Grill
Description
