56 User Manual 10H52188UM51 - Rev. 1 - 09/2011
Options Liebert NXC
8.4 Liebert NXC Input Transformer Version
This UPS includes an insulation transformer at the UPS input. This transformer is installed in place of the batteries and provides
electrical insulation between the load and the input mains utility.
UPS with input insulating transformer
8.5 Liebert NXC Output Transformer Version
This UPS includes an insulation transformer at the UPS output. This transformer is installed in place of the batteries and provides
electrical insulation between the UPS output and the load.
UPS with output insulating transformer
must be not connected!
UPS MODULE
RECT INV
CHARGER
COMMUNICATION
PORTS
OP. AND DISP.
PANEL
OUTPUT: 3AC
