5. Technical specifications
Position at lower level*
Staircase*
Position at upper level*
* The FlexStep lift is shown here with the “Raise-to-fold” ramp (ramp with extra length) and
automatic onboard barrier.
All scale drawings for the FlexStep lift models can be configured on
Liftup’s product configurator: https://config.liftup.dk/
Specifications:
Power supply*: 100-240 V/50 Hz (1.1 A) Max: 90 W, Standby < 6 W
* The FlexStep power delivery system and interface to the power
grid, is fully UL compliant.
Lift capacity: 400 kg
Lift height: 240-1250 mm.
Platform size:
Internal dimensions: W 700/800/900/1000 mm - L 900 mm - 1800 mm
External dimensions: W 930-1230 mm - L 1095-2010 mm
Unladen weight: 125-205 kg
Noise level: < 70 dB
1) 2)
1)
The noise level is an average and, for a short period, noise could
occur at > 70 dB
2)
When “Raise-To-Fold” (RTF) has been activated in connection
with ramp selection (optional equipment), the noise level is
specified as: < 80 dB
Water and dust: > 50 V: IP67 (Power Supply) /< 50 V: IP23 /< 10 V: IPxx
Lift speed v. temperature
°C
mm/sec.
+40 ˚C to +5 ˚C
< 60 mm
+5 ˚C to -10 ˚C
20 mm
-10 ˚C to -20 ˚C
10 mm
Max. 200 kg
-20 ˚C to -25 ˚C
10 mm
