USER MANUAL – FLEXSTEP V2 – US VERSION 08.02

10.3 Operation of the FlexStep from the LOWER level

The lift is activated from the LOWER level by pressing and holding in

the arrow key () on the operating panel.

The staircase is transformed into a platform and moves to the LOWER

level. When the platform reaches the lower level, the roll-off

protection/automatic onboard barrier are lowered (figs. 5 and 6) and

the ramp acts as a drive-on/drive off ramp (fig. 5). Drive onto the

platform carefully and lock/brake the wheelchair (fig. 7).

Press and hold in the arrow key (). The platform then moves to the

UPPER level and the barrier/door at the upper level is opened so that

it is possible to exit at the UPPER platform. Drive away from the

platform carefully (fig. 8).

Fig. 5:

The ramp lowers

Fig. 6:

The automatic

onboard barrier

(optional equipment)

lowers

Fig. 7:

Drive onto the

platform

Fig. 8:

Drive off the platform

10.4 Operation of FlexStep on the platform

The FlexStep is operated as a wheelchair lift by means of the operating

panel mounted on the staircase rail or using the remote control

(optional equipment). The panel on the platform only works when the

FlexStep is in platform mode. The operating panels on the wall/remote

control (optional equipment) can also help to control the up and down

movement of the platform.

• To move the platform up, press the arrow button () and keep pressing it until the lift

stops and the door or barrier, as applicable, opens.

• To move the platform down, press the arrow key () and keep pressing on it until the lift

stops, the automatic onboard barrier lowers and the exit ramp moves down and acts as a

drive-on/drive off ramp.
