6.2.3. Rear view (inputs, output and power)
26 mm
100,4 mm
6.2.1. Bottom view
16.4 mm
2x M3 thread
16.5 mm
16,4 mm
For rack mounting, cross recessed M3 (max. 10 mm long) screws must be used.
