8. Specifications
Video
Standard .................................................................................................... DVI 1.0
Color depth ................................................................................ 24 bits, 8 bit/color
Format ..................................................................................................... RGB only
Data rate ........................... all between 25 Mbps and 1.65 Gbps /TMDS channel
Resolutions ..................................... all between 640x480 and 1920x1200@60Hz
HDTV resolutions .................................................................... 720p, 1080i, 1080p
HDCP compliant ................................................................................................ No
Input equalization (RX100) ......................................... +40 dB, automatic, manual
Reclocking (RX100) .................................................................. TMDS Reclocking
EDID Emulation (TX200/TX300) ... Yes, 50 factory preset, 50 user programmable
EDID Support (TX200/TX300) ....................................... 256 Byte Extended EDID
General
Connectors ................................................. 29-pole DVI-I digital only, CAT6 RJ45
Number of DVI inputs (TX200/TX300) ................................................ 1 single link
Number of DVI outputs (RX100) ......................................................... 1 single link
Number of CATx inputs (RX100) ........................................................ 1 single link
Number of CATx outputs (TX200) ...................................................... 1 single link
Number of CATx outputs (TX300) ...................................................... 2 single link
+5V output current (DVI) .............. 500 mA continuous with overcurrent protection
Power adaptor ............................... 100-240 V AC 50/60 Hz 0.6A to +5V DC 2.6A
Power consumption (TX200/TX300) ..................................................... 4 W typical
...................................... 6 W max when powering a fiber extender on DVI output
Power consumption (RX100) ................................................................ 3 W typical
...................................... 6 W max when powering a fiber extender on DVI output
Compliance ....................................................................................................... CE
EMI/EMC ................................................................................... EN 55022 Class B
Safety ....................................................... UL, CUL, GS, CR, RCM, PSE, Class II
Warranty ................................................................................................... 3 years
Enclosure
Rack mountable ............................................................................................... Yes
Material ............................................................................................... 1 mm Metal
Dimensions ................................................ 100,4 mm W x 67,6 mm D x 26 mm H
Net Weight (TX200) ...................................................................................... 230 g
Net Weight (TX300) ...................................................................................... 240 g
Net Weight (RX100) ...................................................................................... 230 g
