DVI-TP-TX200/TX300/RX100
User’s Manual Rev. 1.0
Page 7 / 29
2.3. Receiver features (DVI-TP-RX100)
Input Equalization – The CATx input is compensated for up to 40 dB high
frequency cable loss. Automatic and user adjustable modes are
available to allow for precise setting of equalization.
TMDS reclocking – (removes jitter caused by long cables) the DVI OUTPUT has a
clean, jitter free signal, eliminating signal instability and
distortion caused by long cable or connector reflections.
Signal Present and Monitor Connected LEDs – Two LEDs indicate when a valid
DVI signal is detected and when a display device is connected
and it is sending a Hot Plug signal.
Supports all HDTV resolutions – 720p, 1080i and 1080p etc without HDCP
enoding. Unencrypted signals with up to 165 MHz pixel clock
frequency - regardless of the resolution - are passed through.
Front panel control – EQ mode selection button and 25-turn potenciometer are
available for precise equalization setting. Red and green LEDs
on the front panel indicate the currently selected EQ mode.
Fiber cable support – Self powered DVI fiber cables using +5V from DVI sources
(VGA cards, etc.) usually consume more than 55 mA, which
load is the maximum allowed by DVI 1.0 standard. DVI-TP-
RX100 supports +5V 500 mA constant current output on DVI
OUTPUT to power long distance fiber optical transmitters.
Universal power adaptor – DVI-TP-RX100 is equipped with a universal +5V
power adaptor, which accepts AC voltages from 100 to 240
Volts with 50 or 60 Hz line frequency.
