LMAIM1501 LY Installation and Maintenance for LY 1001, LY 2001 and LY 3001 6-11

Figure 6.8 – LY 2001/3001 Cover and Associated Parts

108

106

107

145

Lim

itor

que

Note: Refer to certified data

for construction purposes

101-458-0019-4 Rev A.

186

Flow Control Division
