Limitorque LY Series - Parts Lists; Table 8.1 - LY 1001 Parts List

LMAIM1501 LY Installation and Maintenance for LY 1001, LY 2001 and LY 3001 8-1
8 Parts Lists
Table 8.1 – LY 1001 Parts List (Refer to Figures 6.5, 6.6 and 6.7)
Piece # Description Qty Piece # Description Qty
1 LY 1001 Housing 1 55 Retaining Washer
2 Top Plate 1 56 Hex Head Cap Screw 4
3 Control Cover 1 57 Lockwasher 4
4 Conduit Adapter 1 58 Mechanical Stop (Set Screw) 2
5 Disc Spring Cap 1 59 Set Screw 2
6 Motor 1 61 Hex Head Cap Screw 4
7 Limit Switch Assembly 4 62 Lockwasher 4
8 Torque Switch Assembly 1 63 Hex Head Cap Screw 2
9 Terminal Strip 2 64 Lockwasher 2
10 Drive Sleeve 1 65 Hex Head Cap Screw 2
11 Capacitor Varies 66 Lockwasher 2
12 Capacitor Clamp 1 67 Hex Head Cap Screw 6
13 Clutch Sleeve 1 68 Lockwasher 6
14 Worm Shaft* 1 70 Roll Pin – HW Input Shaft 1
15 Worm* 1 72 Hex Head Cap Screw 1
16 Handwheel Clutch 1 73 Lockwasher 1
18 Input Worm Gear 1 79 Fillister HD Machine Screw 1
19 Ball Bearing* 2 80 Lockwasher 2
20 Disc Spring* 6 81 Terminal Bracket 1
21 Spring Spacer* 2 82 Fillister HD Machine Screw 2
22 Torque Switch Spacer* 1 83 Lockwasher Internal Tooth 2
23 Worm Spacer* 2 84 Pipe Plug 1
24 Ball Bearing 1 85 Pipe Plug 1
26 Thrust Washer 2 86 Hex Head Screw 4
27 Thrust Bearing 1 94 Roll Pin* 1
30 Spring Sleeve* 1 96 Groove Pin* 1
31 Input Worm Shaft 1 97 Fillister HD Machine Screw. 2
32 Torque Nut 1 98 Lockwasher Internal Tooth 2
33 Ball Bearing 1 99 Flat Washer* 1
34 Handwheel Cap 1 100 Flexloc Nut* 1
37 Handwheel Input Shaft 1 106 Dial Window 1
40 Bearing Stop* 1 108 Dial Window Retaining Plate 1
41 Handwheel 1 109 Dial Window Gasket 1
44 Declutch Shaft 1 110 Terminal Strip 1
45 Declutch Lever 1 111 Press-on Retaining Clip 15
46 Declutch Fork Assembly 1 112 Roll Pin - Handwheel 1
47 Declutch Return Spring 1 113 Retaining Ring 1
48 Dowel Pin 1 114 Retaining Ring 1
50 Declutch Latch – Right 1 118 Key* 1
51 Declutch Latch – Left 1 120 Heater 1
52 Ball Bearing 2 121 Roll Pin – Declutch Handle 1
53 Pinion Gear 1 123 Roll Pin – Declutch Shaft 1
54 Motor Pinion Gear 1 124 Roll Pin – Input Shaft 1
