LMAIM1501 LY Installation and Maintenance for LY 1001, LY 2001 and LY 3001 2-1

2 Product Capabilities and Features

The LY actuator controls the opening and closing travel of the valve and limits torque through the torque switches provided. As a

result, all valve-operating parts are protected from overload, improper seating, and foreign obstructions.

LY actuators may be mounted on any size valve in almost any position or location.

Microprocessor-based control and monitoring devices are available for installation on your actuator. Contact your local

Limitorque distributor or Limitorque sales office for further information.

Figure 2.1 – LY Actuator (LY 1001 shown)

Flow Control Division

Limitorque Actuation Systems

Limitorque

100

Housing

Position Indication Window

Control Cover

Conduit Adapter

Declutch Lever

Handwheel typically

clockwise turn to CLOSE

and counterclockwise

turn to OPEN
